Assemble the Attaching tubes CROSSBAR , MF6-1 to MF-1,MF-2 & MF-5 connectors.
CROSSBAR
STEP C
MF6-1
MF-1
MF-2
MF-5
MF-5
MF-5
MF-2
MF-5
MF-2
DETAIL VIEW
DETAIL VIEW
MF6-1
MF-2
