STEP G
Attach the CROSSBAR & POSTS to the BASE FRAME using the connectors.MF-2
CROSSBAR TO BASE FRAME
MF6-2
MF6-3
MF-2
MF6-2
MF-2
MF6-3
DETAIL VIEW
MF-2
MF6-2
MF6-3
