Quicksilver Activ 605 Open - Dash Layout

Quicksilver 605OP — General Informaon
8
GPS/ Depth sounder
Bow windlass switch
Stereo
Acve trim
DAB antenna
11. Dash Layout (standard equipment)
SC1000 speedometer
SC1000 tachometer
Hydraulic steering
Steering wheel
Air temperature sensor
Helm switch panel
Engine shutdown switch
Engine key
Engine throle shi control
12V receptacle
Cup holder
Please note that operator vision from the helm may be obstructed by high trim angles of the cra,
along with other factors such as outboard engine trim angles, hull trim plane angles, loading and load
distribuon, speed & acceleraon, transion from displacement to planing mode, sea condions, rain
and spray, darkness and fog, interior lights, posion of tops and curtains, and persons or movable
gear in the operator’s eld of vision.
Dash Layout (oponal equipment)
