Quicksilver 605OP — System & Component Overview and Operaon
Wear the lanyard at all mes when operang the boat. Use
it to stop only in an emergency. DO NOT use it to shut o
the engine during normal operaon
10. SmartCra
TM
System Gauges
The instrument package on your boat includes a SmartCra
TM
tachometer and speedometer mul-
gauge system. By pressing the “mode” buon on the gauge, specic informaon vital to the safe
operaon of the vessel can be displayed. Refer to your SmartCra
TM
gauge owner’s manual for
specic informaon on how to get the most out of the mul-gauge display.
In addion, Quicksilver® oers an oponal factory installed GPS along with Mercury’s Vessel Link
system. If both are installed, the same engine data that you see on your SmartCra
TM
gauges can be
displayed on your GPS. Refer to the GPS owner’s manual for more specic informaon regarding
instrucons and warranty.
11. Acve Trim (oponal)
Your boat may come equipped with the Acve Trim system from Mercury. Acve Trim automacally
adjusts the engine trim based on boat speed to opmize performance and fuel economy. The system
9. Emergency Engine Shutdown Switch
Your boat is equipped with an engine shutdown safety switch. The switch is located at the helm
between the steering wheel and the engine control unit. The ignion shutdown switch incorporates a
shut-o switch and a lanyard. Before operang the boat, one end of the lanyard must be connected to
the shut-o switch while the other end is connected to the operator. If an emergency arises where
the engine must be shut down, pull the lanyard cord to release it from the shut-o switch, which in
turn shuts down the engine. This switch is designed to shut the engine o when the operator of the
boat leaves the control staon, either accidently by falling into the boat, or by being ejected
overboard.
The lanyard should be long enough to prevent inadvertent acvaon. Do not let the lanyard become
entangled.
Emergency Engine Shutdown Switch
Engine shutdown safety switch
Switch clip (aached to switch)
Lanyard
Switch clip (aached to operator)
