Quicksilver 675SD — System & Component Overview and Operaon
22
Mechanical & DTS Controls
8. Engine Controls
Depending on the engine installed on your boat, you will either have a mechanical gear shi/throle
control unit or a “drive by wire” Digital Throle and Shi (DTS®) control unit. The control unit, located
to the starboard of the steering wheel, acvates both the shiing and throle for the engine.
To start the engine, the control unit must be in the NEUTRAL posion. When in neutral, the engine is
running, but the propeller is not spinning. There is a “Throle-Only” buon that when pressed, will
allow you to operate the throle without the propeller spinning. On the mechanical shi controller,
the buon is located at the center of the throle control, and when moved back to the center
posion, the buon will automacally re-engage the shiing mechanism.
For the DTS control, the “Throle-Only” buon is located on the control funcon pad. To engage,
press the “Throle-Only” buon on the keypad when the engine is in neutral. A light located above
the “Throle-Only” buon will turn on and the green neutral light will begin to ash. When you place
the ERC in gear, the warning horn will beep, however, the propeller is not turning. To disengage,
return the ERC lever back to neutral and press the “Throle-Only” buon. The light located above the
“Throle-Only” buon will turn o and the green neutral light stops ashing and remains illuminated.
Moving the control lever forward from neutral engages the forward gear and throle advance.
Moving the control lever backwards from neutral engages the reverse gear and thrust. The throle
lever controls the RPM of the engine and the speed of the boat.
Power Trim & Tilt
The power trim, located on the side of the gear shi throle handle, allows you to raise and lower the
engine for trailering and launching the boat. It also allows you to adjust the engine to create the
opmum run angle for the boat to achieve best all around performance (fuel consumpon, speed).
REFER TO THE ENGINE MANUFACTURER’S MANUAL FOR COMPLETE INSTRUCTIONS, INFORMATION
AND WARRANTY.
Engine trim
“Throle Only” buon
Track pad
9. Emergency Engine Shutdown Switch
Your boat is equipped with an engine shutdown safety switch. The switch is located at the helm
between the steering wheel and the engine control unit. The ignion shutdown switch incorporates a
shut-o switch and a lanyard. Before operang the boat, one end of the lanyard must be connected to
the shut-o switch while the other end is connected to the operator. If an emergency arises where
the engine must be shut down, pull the lanyard cord to release it from the shut-o switch, which in
turn shuts down the engine. This switch is designed to shut the engine o when the operator of the
