GENERAL SAFETY INSTRUCTIONS
1. Read Instructions - All safety and operation instructions must be read. Failure to read and follow
instructions as stated in this guide may void applicable warranty.
2. Retain Instructions - The safety and operating instructions should be kept for future reference.
3. Heed Warnings - All warnings should be followed.
4. Follow Instructions - All installation and operating instructions should be followed.
5. Heat - The QuietCool system should be situated away from heat sources.
6. Damage Requiring Service - Only qualified service personnel should service the QuietCool system.
The user should not attempt to service the product.
7. Building Codes - Always follow Local Building Codes when installing appliances
CONTENTS
1. SYSTEM OVERVIEW ..............................................................1
1.1 Introduction ..............................................................1
1.2 Features .................................................................1
1.3 System Venting Requirements .............................................2
2. INSTALLATION ..................................................................3
2.1 Installing AFR Model Fans .................................................3
2.2 Installing RM Model Fans .................................................5
3. WIRING .........................................................................8
3.1 Specialty Fan Wiring - Smart ...............................................8
3.2 Specialty Fan Wiring - Thermostat (Robert Shaw) ...........................9
3.3 Specialty Fan Wiring - Timer ..............................................10
4. SYSTEM OPERATING INSTRUCTIONS ...........................................11
4.1 QuietCool Smart Attic Fan ................................................11
4.2 QuietCool Roof Mount Fans ...............................................11
WARRANTY .......................................................................13
