QuietCool AFR SMT ES-2.0 User Manual

QUIETCOOLSYSTEMS.COM 5
WELCOME
INSTALLATION
WIRING OPERATION
WARRANTY
READ BEFORE ATTEMPTING TO INSTALL AN AFR FAN
GETTING STARTED
NOTE: Always follow local building codes because the fan may require specic fasteners or
anchoring systems not discussed in this installation guide. Installation should be done by a
licensed roong contractor.
GENERAL SAFETY INFORMATION
1. READ INSTRUCTIONS - All safety and operation instructions must be read.
2. RETAIN INSTRUCTIONS - The safety and operating instructions should be kept for future reference.
3. HEED WARNINGS - All warnings should be followed.
4. FOLLOW INSTRUCTIONS - All installation and operating instructions should be followed.
5. WATER - The QuietCool system should not be used near water. If you live in a very humid climate,
be sure to cover your damper box with insulation to reduce condensation.
6. HEAT - The QuietCool system should be situated away from heat sources.
7. DAMAGE REQUIRING SERVICE - Only qualied service personnel should service the QuietCool system.
The user should not attempt to service the product.
8. SAFETY PRECAUTIONS -
+ Do not install the fan in wet or windy conditions
+ Tie-off both yourself and your equipment when working on steep pitched roofs to avoid falls
+ Wear safety glasses and protective gloves when using power tools
+ Always wear slip-resistant shoes when working on the roof
+ Do not cut through any rafters or structural members of the roof during installation
TOOLS/MATERIALS YOU WILL NEED
+ Cordless Drill with Nut Driver
+ Roong Nails
+ Reciprocating Saw
+ Measuring Tape
CHOOSING THE RIGHT LOCATION
Choose a location to install your QuietCool roof mounted fan that allows for balanced airow throughout the
attic space. We always recommend the fan to be installed centrally located on the roof three feet below the
ridge line. This will allow you to access the fan very easily. Your roof mount fan should not be installed any
closer than within 5 feet to an existing passive vent, ridge vent, or additional fan unit.
IMPORTANT: Do not cut through any rafters or structural members while cutting the fan hole.
Only cut out the roof decking.
!!
!!
+ Weatherproof Roong Grade Sealant
+ Roong Knife
+ Ladder Marker or Carpenter Pencil
+ Secondary Flashing Material (for tile roof)
ROOF PITCH REQUIREMENTS (MAX ROOF PITCH 8/12)
For roofs with less than a 3/12 roof pitch, the fan should be curb mounted
