GENERAL SAFETY INSTRUCTIONS
1. Read Instructions - All safety and operation instructions must be read.
2. Retain Instructions - The safety and operating instructions should be kept for future reference.
3. Heed Warnings - All warnings should be followed.
4. Follow Instructions - All installation and operating instructions should be followed.
5. Water - The QuietCool system should not be used near water. If you live in a very humid climate, be sure
to cover your damper box with insulation to reduce condensation.
6. Heat - The QuietCool system should be situated away from heat sources.
7. Damage Requiring Service - Only qualified service personnel should service the QuietCool system.
The user should not attempt to service the product.
CONTENTS
1. QUICKSTART GUIDE .....................................................3
1-1 Special Instructions ...............................................3
1-2 Product Diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1-3 When to Run Fans ..................................................5
1-4 Where to Start Cooling .............................................5
1-5 Indoor Air Quality ..................................................5
2. SYSTEM OVERVIEW .....................................................6
2-1 Introduction .......................................................6
2-2 Features ..........................................................6
2-3 System Venting Recommendations .................................7
3. INSTALLATION ..........................................................8
3-1 Installing QuietCool ................................................8
3-2 Installing Vertical Adapter ........................................12
4. WIRING ................................................................13
4-1 Single Speed Wiring ...............................................14
4-2 Two Speed Wiring .................................................15
ENERGY SAVER CLASSIC WARRANTY ...................................19
SERIAL NUMBER ..........................................BACK COVER
ADVANCED WHOLE HOUSE FANS
®
QC Manufacturing, Inc.
43352 Business Park Drive
Temecula, CA 92590
PH 951.325.6340
FX 951.325.6351
QuietCoolSystems.com
