Quietside QS09-VP115 User Manual

2
Technical Information
Service Manual
2. Specications
2.1 Specication Sheet
Model
QS09-VJ115
QS09-VP115
QS12-VJ115
QS12-VP115
Product Code CB16300021_K90639 CB16300041_K90639
Power
Supply
Rated Voltage V~ 115 115
Rated Frequency Hz 60 60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity(Min~Max) Btu/h 9000(4436~11997) 12000(4500~13999)
Heating Capacity(Min~Max) Btu/h 9500(3412~12488) 13000(3753~14498)
Cooling Power Input(Min~Max) W 660(120~1300) 1000(120~1450)
Heating Power Input(Min~Max) W 700(220~1350) 1200(220~1500)
Cooling Current Input A 16 17.5
Heating Current Input A 16.5 18
Rated Input W 1350 1500
Rated Current A 16.5 18
Air Flow Volume (SH/H/M/L) CFM 300/277/253/218 330/294/253/218
Dehumidifying Volume Pint/h 1.69 2.96
EER (Btu/h)/W 13.64 12
COP (Btu/h)/W 13.57 10.83
SEER 22 20
HSPF 9.8 9.6
Application Area m
2
12-18 16-24
Indoor Unit
Indoor Unit Model QS09-VJ115 QS12-VJ115
Indoor Unit Product Code CB163N0021_K90639 CB163N0041_K90639
Indoor Unit Fan Type Cross-ow Cross-ow
Indoor Unit Fan Diameter Length(DXL) inch Φ3 5/8X25 2/5 Φ3 5/8X25 2/5
Cooling Speed (SH/H/M/L) r/min 1260/1070/900/730 1290/1070/900/690
Heating Speed (SH/H/M/L) r/min 1280/1050/980/920 1280/1050/980/920
Indoor Unit Fan Motor Power Output W 20 20
Indoor Unit Fan Motor RLA A 0.38 0.38
Indoor Unit Fan Motor Capacitor μF 4 4
Heater Power Input W / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter inch 0.28 0.28
Evaporator Row-n Gap inch 2-1/16 2-1/16
Evaporator Coil Length (LXDXW) inch 25 2/5X1X10 1/2 25 2/5X1X10 1/2
Swing Motor Model MP24AA MP24AA
Swing Motor Power Output W 2.4 2.4
Fuse Current A 3.15 3.15
Sound Pressure Level (SH/H/M/L) dB (A) 38/34/30/26 40/36/32/26
Sound Power Level (SH/H/M/L) dB (A) 48/44/40/36 50/46/42/36
Dimension (WXHXD) inch 33 1/4X10 5/6X7 33 1/4X10 5/6X7
Dimension of Carton Box (LXWXH) inch 36X10X14 36X10X14
Dimension of Package (LXWXH) inch 36 1/7X 10 1/6X14 4/7 36 1/7X 10 1/6X14 4/7
Indoor Unit Net Weight lb 22.1 22.1
Indoor Unit Gross Weight lb 28.7 28.7

Quietside QS09-VP115 Specifications

General

Brand	Quietside
Model	QS09-VP115
Category	Air Conditioner
Language	English
