Page 6 For technical questions, please call 1-888-866-5797. Item 58950

Parts List and Diagram

Parts List

Part Description Qty

1 Socket With Magnet 1

2 C Clip 1

3 Adjustment Ring 1

4 Positioning Spring 1

5 Scale Ring 1

6 Hex Screw 3

7 Washer 3

8 Steel Ball 3

9 Spring 3

10 Secondary Scale Ring 1

11 Mandrel Extension 1

12 Aluminum Internal Tube 1

13 Fixing Rivet 4

14 Adjustable Lever Housing 1

Part Description Qty

15 Bolt 4

16 Adjustable Lever 1

17 Steel Ball 13

18 Washer 2

19 Torque Spring 1

20 Feed Sleeve 1

21 Post Sleeve 1

22 Washer 2

23 Needle Bearing 1

24 Screw 1

25 Screw 1

26 Flat Head Screw 1

27 Plastic Grip 1

28 End Cap 1

Record Product’s Serial Number Here:

Note: If product has no serial number, record month and year of purchase instead.

Note: Some parts are listed and shown for illustration purposes only, and are not available

individually as replacement parts. Specify UPC 193175451781 when ordering parts.
