Connecting water
• N.B. The Quooker operates under water supply pressure and must always be
fitted with the inlet combination (supplied).
• The Quooker boiling-water tap must be connected according to the locally
applicable regulations.
• Position the inlet combination at such a height that the difference in height
between it and the drain is the maximum possible to allow the expansion
water to run off (see D4).
1 Cutting through
cold water pipe
Cut through the cold water pipe at a
suitable point.
2 Making space
for T-piece
3 Connecting
T-piece
Position the T-piece between the pipe
sections and tighten the clamping nuts.
4 Fitting the inlet
combination
Connect the inlet combination to the
T-piece with a copper tube (15 mm).
Screw the transparent funnel in the
hole in the inlet combination provided
for this purpose.
1
2
3 4
C
