R82 Heron - Technical Data

37
support.R82.org
Technical Data
Battery: BAJ1 - IPX5
• Capacity 2.9 Ah - 24V DC
• Duty cycle: Max. 10% or 2 min. use then 18
min. without use
The batteries have a maximum life of 4 years but
this can vary depending upon the conditions of
use and charging practices
Control box: CBJC - IPX4
• Output voltage 24V DC
Battery charger: CHJ2 - IPX5
• Mains: 100 - 240VAC/50-60 Hz switch mode
• Charging current: Max. 650 mA
Actuator: LA40 - IPX6
• Motor: 24-33 V DC, Standard motor
• Noise level: ≤ 50 db (A)
Handset: HB 30 IPX4
Detachable parts
• Handset - HB 30
• Battery - BAJ1
• Control box - CBJC
Applied part
• Handset - HB 30
Ambient and surface temperature
The table below illustrates how long time it takes
for the surfaces of the Heron to reach an ambient
temperature of 20°C from -10°C and+50°C.
Surface temperature
-10°C to +20°C 108 min
+50°C to +20°C 129 min
Second Digit: Liquids
Protection of the equipment inside the enclosure
against harmful ingress of water.
IPX0 No protection
IPX1 Protection against vertically falling
drops of water e.g. condensation
IPX2 Protection against direct sprays of
water up to 15° from the vertical
IPX3 Protected against direct sprays of
water up to 60° from the vertical
IPX4 Protection against water sprayed
from all directions - limited ingress
permitted
IPX5 Protected against low pressure jets
of water from all directions - limited
ingress
IPX6 Protected against temporary
ooding of water, e.g. for use
on ship decks - limited ingress
permitted
IPX7 Protected against the effect of
immersion between 15 cm and 1 m
IPX8 Protects against long periods of
immersion under pressure
IP-Rating table
First Digit: Solids
The rst digit indicates the level of protection
that the enclosure provides against access to
hazardous parts (e.g., electrical conductors,
moving parts) and the ingress of solid foreign
objects
IP0X No protection against contact and
ingress of objects
IP1X Any large surface of the body,
such as the back of the hand, but
no protection against deliberate
contact with a body part.
IP2X Fingers or similar objects.
IPX3 Tools, thick wires, etc.
IPX4 Most wires, screws, etc.
IPX5 Ingress of dust is not entirely
prevented, but it must not enter in
sufcient quantity to interfere with
the satisfactory operation of the
equipment; complete protection
against contact.
IP6X No ingress of dust; complete
protection against contact.
Environmental conditions
• Operating temperature: +5°C to +40°C
• Relative humidity: 20% to 90%
• Atmospheric pressure: 800 to 1060 hPa
• Storage temperature: -10°C to +50°C
