Installing your Lightcloud Blue Device
(cont’d)
First install load
3-way Installation
5
Single Pole Installation
4
Option 1:
Control non-Lightcloud Blue enabled products.
Run wire for Hot, Neutral (optional), Ground and Load.
See Wiring Scheme 1 or 2.
Option 2:
Control Lightcloud Blue enabled products.
Remotely run wire for Hot, Neutral, and Ground.
See Wiring Scheme 1.
(you cannot attach the load to alightcloud blue enabled
fixture)
Control non-Lightcloud Blue enabled products.
Run wire for Hot, Neutral
Then install Xdim with no load for remote control
(optional), Ground, Load,
Control Lightcloud Blue enabled products.
Run wire for Hot, Neutral and Ground.
Dimmers will be assigned to the same Area in the mobile
app to work as a 3-way switch.
