2g
• Selectable phase control load switch
Phase Selector Switch
Basic Operation
(cont’d)
2c
2b
Reset Button
2f
Power Cutoff Switch
2d
Status Indicator
2e
• Turn lights OFF: Single press
• Decrease brightness: press and hold, release at desired
setting
• Decrease to minimum brightness level: Double press
Off/Down Paddle
• Confirms the dimmer is receiving power
Power Indicator
• Pull switch until it stops to cut power to this dimmer and
to the load or to detach the Control Component
• Represents the connectivity to the Lightcloud Blue network
(Need to include status color denitions)
• Press and for 10 seconds
To Next Page
