10. Flash Memories
The flash memories listed in Table 3 below have been qualified for use with the Rabbit
2000 microprocessor.
Table 3. 32-Pin Flash Memories Supported by the Rabbit 2000
Vendor
Device
Name
Device
Size
(bytes)
Sector
Size
(bytes)
Number
of
Sectors
Write
Mode
Best
Access
Time
(ns)
Operating
Voltage
(V)
Package
Types*
Dynamic
C Version
Atmel AT29C010 128K 128 1024 sector 70 4.5–5.5 1, 2, 4All
Atmel AT29LV010 128K 128 1024 sector 150 3.0–3.6 2, 4All
Atmel AT29C020 256K 256 1024 sector 70 4.5–5.5 1, 2, 4
6.50 and
later
Atmel AT29LV020 256K 256 1024 sector 200 3.0–3.6 2, 4
6.50 and
later
Atmel AT29C040 512K 256 2048 sector 120 4.5–5.5 1, 4
6.50 and
later
Atmel AT29LV040 512K 256 2048 sector 200 3.0–3.6 4
6.50 and
later
Mosel/Vitelic V29C51001T 128K 512 256 byte 45 4.5–5.5 1, 2, 4
6.50 and
later
Mosel/Vitelic V29C51001B 128K 512 256 byte 45 4.5–5.5 1, 2, 4
6.50 and
later
Mosel/Vitelic V29C51002T 256K 512 512 byte 55 4.5–5.5 1, 2, 4
6.50 and
later
Mosel/Vitelic V29C51002B 256K 512 512 byte 55 4.5–5.5 1, 2, 4
6.50 and
later
Mosel/Vitelic V29C51004T 512K 1024 512 byte 70 4.5–5.5 2, 4
6.50 and
later
Mosel/Vitelic V29C51004B 512K 1024 512 byte 70 4.5–5.5 2, 4
6.50 and
later
SST SST29EE512 64K 128 512 sector 70 4.5–5.5 1, 2, 3, 4
6.50 and
later**
SST SST29LE512 64K 128 512 sector 150 3.0–3.6 1, 2, 3, 4
6.50 and
later**
SST SST29EE010 128K 128 1024 sector 90 4.5–5.5 1, 2, 3, 4All
SST SST29LE010 128K 128 1024 sector 150 3.0–3.6 1, 2, 3, 4All
SST SST39SF020 256K 4096 64 byte 45 4.5–5.5 1, 2, 3
6.50 and
later
Winbond W29C020CT 256K 128 2048 sector 70 4.5–5.5 1, 2, 4All
**
