Racelogic VBOX LapTimer - General Specification; GPS Specification

General Specification
Environmental and Physical
Unit Connection 1 x Lemo 5 way socket 1 x Lemo 2 way socket
IP Rating IP31 Rating
Operating Temp -20 to +70°C
Power 1.5 W
Input Voltage 7 - 30 V DC
Dimensions 120 mm x 50 mm x 24.5 mm (exc. connectors)
Mounting Hole Dimensions 7.6 mm Depth, 1/4" UNC
Weight 178 g (exc. cable)
GPS Specification
Velocity
Accuracy 0.1 km/h
Units km/h or mph
Update rate 20 Hz or 10 Hz*
Maximum velocity 1800 km/h
Minimum velocity 0.1 km/h
Resolution 0.01 km/h
*Version 1 units 20Hz only, Version 2 units 10Hz only.
