Advanced Programming
Verbatim Owner's Manual 6-3
Programming Code Table (Page 1 of 8)
Code Description & Comments Default Range/Values Notes Section
See p. 6-2
Channel Status Reading
0ZZ Reads status of channel ZZ 6.2.1
0ZZ0 Reads actual open/closed circuit 6.2.1
status directly
Message Recording and Reviewing
100 Records Station ID message 1, 2, 10 4.3, 6.2.2
1ZZ Records channel ZZ alarm message 1, 2, 10 4.3, 6.2.2
2ZZ Records channel ZZ normal message 1, 2, 10 4.3, 6.2.2
3ZZ Reviews channel ZZ both messages 1 4, 4.3,
ZZ=00 for Station ID msg 6.2.2
911 Reads current record rate 4.2
and available record time
912 Autoextend: sets optimum 4.2
record rate for recited msg
913 N Sets recording rate Rate 1 Rate 1-4 4.3
914 N Inserts N in place of 1 in canned Station 1 1-16 digits 4.3
station ID message
Channel Programming (Configuration)
500 Sets current status as normal 3.3, 6.2.3
for all channels
500 N Sets all inputs to config parameter N normally 0/1/2/3 3.3, 6.2.3
closed 0 = disarmed
1 = normally closed (default)
2 = normally open
3 = no alarm
5ZZ Reads alarm criteria for channel ZZ 1 6.2.3
5ZZ 0 Disables channel ZZ 13 3.3, 6.2.3
5ZZ 1 Sets chan ZZ normally closed 1 3.3, 6.2.3
5ZZ 2 Sets chan ZZ normally open 1 3.3, 6.2.3
5ZZ 3 Sets chan ZZ for no alarm 1 3.3, 6.2.3
(status report only)
5ZZ 4 Sets chan ZZ for run time 1 3.3, 6.2.4
meter operation
5ZZ 4 V Preset starting value 0.0 hrs 0.0-99,999.9 hrs 1 6.2.4
5ZZ 7 N Pulse totalizer: ACTIVATES 12, 2 6.2.5
with starting value N
5ZZ 8 N Pulse totalizer: sets scale factor N 12 6.2.5
5ZZ 6 N Pulse totalizer: sets alarm setpoint N 12 6.2.5
with starting value N
