Advanced Programming
6-4 Verbatim Owner's Manual
Programming Code (Page 2 of 8)
Code Description & Comments Default Range/Values Notes Section
See p. 6-2
Alarm Trip Delays
600 Reads power failure alarm trip delay 6.2.6
600 V Sets power failure alarm trip delay to V 0.1 min 0.1-999.9 min 6.2.6
6ZZ Reads chan ZZ alarm trip delay 6.2.6
6ZZ V Sets chan ZZ individual alarm trip 2 sec 0.1-9999.9 sec 1 6.2.6
delay to V
6ZZ Returns chan ZZ individual alarm 2 sec 1 6.2.6
POINT trip delay to default
902 V Sets global (all channels) alarm trip 2 sec 0.1-9999.9 sec 6.2.6
delay to V seconds
902 Returns global (all channels) 2 sec 6.2.6
POINT alarm trip delay to default
Phone Numbers and Pulse/Tone Dialing
700 Reads special “callback” phone number See Code 924 6.2.18
700 N Sets special “callback” phone # to N 1 - 60 digits 6.2.18
7DN Reads phone number DN 01 - 16 3.2, 6.2.7
DN = 01-16
7DN N Sets phone number DN to N phone # 1 - 60 digits 3 3.2, 6.2.7
N can = up to 60 digits
7DN Clears out phone number DN 3.2, 6.2.7
POINT
900 0/1 Read/Set Call Progress Monitoring 0 (OFF) 0/1 6.2.12
0 = OFF
1 = ON
901 0/1/2 Sets dialing mode Pulse mode 0/1/2 9 6.2.7
0 = pulse
1 = tone
2 = high speed
903 V Sets time between callouts to V 2 min 0.1-99.9 min 6.2.18
906 N Sets ring answer delay to N 1 ring 1 - 20 rings 6.2.18
N = whole number
908 0/1 Sets Autocall ON/OFF OFF 0/1 6.2.18
0 = OFF
1 = ON
909 V Sets Autocall interval to V 24 hrs 0.1-99.9 hrs 6.2.18
916 N Set Automatic 24 hrs 0.1 - 24 hrs 916 POINT 6.2.10
Phone Fault Detect frequency resets to default
917 Set Phone Fault and Auto Tone-Pulse 3 0/1/2/3 6.2.10
0/1/2/3 0 = Phone Fault OFF/Auto Tone-Pulse OFF
1 = Phone Fault ON/Auto Tone-Pulse OFF
2 = Phone Fault OFF/Auto Tone-Pulse ON
3 = Phone Fault ON/Auto Tone-Pulse ON
918 CPM Ring Count 10 rings 5 - 20 rings 6.2.12
928 N Extends length of inserted 1 sec 1 - 10 sec 6.2.7
dialing delays to N sec
