Advanced Programming
Verbatim Owner's Manual 6-5
Programming Code (Page 3 of 8)
Code Description & Comments Default Range/Values Notes Section
See p. 6-2
Alarm Call Grouping
5ZZ 9 Reads channel ZZ alarm call 1 6.2.13
grouping linkage
5ZZ 9 DN Links channel ZZ to Calls all 01 - 16 1 6.2.13
phone numbers DN. phone #s DN = 01-16
5ZZ 9 Clears channel ZZ alarm call 1 6.2.13
POINT grouping linkage.
Alarm Ready Scheduling
935 7 Initializes real-time clock chip 2.3,
on install to 1/6/92 2 6.2.19, 7.9
941 Sets date 01/06/92 2 01/01/94 - 12/13/20 2.3, 7.9
MMDDYYD D (Day Code) is optional:
1 = Sunday
2 = Monday
3 = Tuesday
4 = Wednesday
5 = Thursday
6 = Friday
7 = Saturday
942 Sets time 08:00:00 00:00-23:59:59 2.3, 7.9
HHMMSS (military-24-hour-clock)
961 Read weekday 7.9
rearm/disarm times
961 Sets weekday 1700, RRRR=rearm time, 7.9
RRRR rearm/disarm times 0800 DDDD=disarm time
DDDD (military-24-hour-clock)
962 Reads weekend 7.9
rearm/disarm times
962 Sets weekend 1700, RRRR=rearm time, 7.9
RRRR rearm/disarm times 0800 DDDD=disarm time
DDDD (military-24-hour clock)
963 Reads weekend 7.9
rearm/disarm day of week
963 R D Sets weekend Friday, Monday 7.9
rearm/disarm day of week R = rearm day
D = disarm day
964 Reads holiday rearm date 7.9
964 Sets holiday rearm date 12/24/90 Today - 12/31/20 7.9
MMDDYY MM = month
DD = day
YY = year
965 Reads holiday disarm date 7.9
965 Sets holiday disarm date 12/24/90 The day after the 7.9
MMDDYY holiday rearm date
(see Code 964) -
12/31/20
