Raco Verbatim - Page 46

Advanced Programming
6-6 Verbatim Owner's Manual
Programming Code (Page 4 of 8)
Code Description & Comments Default Range/Values Notes Section
See p. 6-2
Alarm Ready Scheduling . . . Continued from p. 6-5
966 Reads alarm ready 7.9
schedule control number
966 N Sets alarm ready schedule 0 N control 0-7 7.9
control number
0 = OFF
1 = Weekday
2 = Weekend
3 = Weekday and Weekend
4 = Holiday
5 = Weekday and Holiday
6 = Weekend and Holiday
7 = Weekday, Weekend and Holiday
Local Data Logging Programming Codes
935 7 Initialize real-time 2.3,
clock chip on install 6.2.19, 7.9
to 1/6/92 2
941 Sets date. 01/06/92 2 01/01/94-12/31/20 2.3, 7.9
MMDDYYD D (Day Code) is optional:
1 = Sunday
2 = Monday
3 = Tuesday
4 = Wednesday
5 = Thursday
6 = Friday
7 = Saturday
942 Sets time 08:00:00 00:00-23:59:59 2.3, 7.9
HHMMSS (military-24-hour clock)
943 V Sets regular interval OFF 0 = OFF 2.3, 7.9
local printing .1 - 999.9 hrs
944 Prints all current 2.3, 7.9
programming immediately
Analog Input Programming
5 ZZ 1 Sets low signal input value B.1.5
X.XX
5 XX 1 Sets low signal input value B.1.5
POINT to real world point
5 ZZ 2 Sets low signal input spoken value B.1.5
X.XX
5 ZZ 3 Sets high signal input value B.1.5
X.XX
5 ZZ 3 Sets high signal input value B.1.5
POINT to real world point
5 ZZ 4 Sets high signal input spoken value B.1.5
X.XX
