Raco Verbatim - Page 47

Advanced Programming
Verbatim Owner's Manual 6-7
Programming Code (Page 5 of 8)
Code Description & Comments Default Range/Values Notes Section
See p. 6-2
Analog Input Programming . . . Continued from p. 6-6
5 ZZ 5 Sets low setpoint alarm value B.1.5
X.XX
5 ZZ 6 Sets high setpoint alarm value B.1.5
X.XX
5 ZZ 7 Sets analog input signal type 0 0/1/2 B.1.3
0 = 4-20 ma signal
1 = 0-1 VDC signal
2 = RACO TS-705A
Remote Supervisory Control
For all items in this section: N = output number, Range = 01, 02, 03, 04, 05, 06, 07, 08
95 N Reads RSC output #N 14 C.1.3
ON/OFF condition
95 N 0 Turns RSC output C.1.3
#N OFF
95 N 1 Turns RSC output C.1.3
#N OFF
95 N 2 V Turns RSC output #N 1 sec 1 - 99,999 sec C.1.3
ON for V seconds only
95 N 3 V Turns RSC output #N 1 sec 1 - 99,999 sec C.1.3
OFF for V seconds only
9500 Reports ON/OFF status C.1.3
of all outputs
9500 0 Turns OFF all outputs C.1.3
9500 1 Turns ON all outputs C.1.3
9500 8 V Establish default pulse C.1.3
duration in minutes
(When using 95 N 2 or 95 N 3)
9500 9 V Establish default pulse H.2.3
duration in seconds
(When using 95 N 2 or 95 N 3)
Data Acquisition/Central Data Logging
919 V Sets quick intercall time 60 sec 35-999 sec E.2
981 V Return To Normal (RTN) calling 0 0/1/2/3/4/5 See Code 923 E.1, K.4
982 0/1/2 Acknowledgment calls to 0 0/1/2 E.3
central station 0 = 1
1 = ON
2 = resets all alarm
acknowledgment
call status
983 0/1 Modem Automatic Speed Select 1 0/1 E.4
0 = OFF
1 = ON
