Advanced Programming
6-8 Verbatim Owner's Manual
Programming Code (Page 6 of 8)
Code Description & Comments Default Range/Values Notes Section
See p. 6-2
Data Acquisition/Central Data Logging . . . Continued from p. 6-7
984 0/1 Modem High/Low speed selection 1 0/1 E.5
0 = 300
1 = 1200
985 N Data call attempts 3 1 - 10 E.6
986 0/1 Sets answer mode 0 0/1 E.7
0 = Data-to-Voice
1 = Voice Only
987 N Data/Voice autocall calls 0 0/1/2 E.8
0 = Autocalls to Central Station only
1 = Autocalls to personnel numbers only
2 = Autocalls to all numbers
Miscellaneous Programming Items
902 V Sets global (all channels) 2 sec 0.1-9999.9 sec 6.2.6
alarm trip delay to V
904 V Sets alarm reset time to V 1 hour 0.1-99.9 hr 5.6, 6.2.18
905 Clears all acknowledged 6.2.18
alarms and clears reset timers
907 N Sets number of alarm 3 repeats 1-20 repeats 5.3, 6.2.18
message repeats to N
N = whole number
910 N Establishes a security None 0-8 digits 7 6.2.18
access code N
920 V Power failure trip delay 0.1 min 0.1-999.9 min 4 6.2.6
(duplicates function of code 600)
921 0/1 Sets power failure alarm ON 0/1 6.2.6
0 = off
1 = on
922 0/1 Sets alarm reset timers ON 0/1 5 6.2.18
0 = off
1 = on
923 Annunciator Sequence 1 1-4 See also K.4
Values: Code 981
1 = M-1designations
2 = A-1-4 designations
3 = A-1 designations
4 = A-1-4 variant
924 Initiates test callback to phone # 00 unit must be 6.2.18
ARMED
925 0/1 Turns on/off alarm ON 0/1
acknowledgment on call-in to 0 = OFF
dialer. 1 = ON
926 V Sets delay before return to 2 min 1-99.9 min Nonrecurring 6.2.18
normal (Exit Delay) to V Function
