Foot Mounting (with pole insert)
Dimensions: 3.3” x 6.0” x 8.5”
Mounting Bracket Back Plate (pole
mount)
Dimensions: 3.0” x 4.7” x 1.5”
Mounting Pole
Dimensions: 1.2” x 0.8” x 11.8
Screws and Nuts M3 x 29mm
For pole mounting
Screws and Nuts M5 x 35mm
For fixing the mounting foot together
with the mounting bracket plate to an
tube
Universal Screws M4 x 35mm
For fixing the mounting foot to a
wooden surface, or together with
dowels on a stone or concrete
100…240V AC Power Adapter
