Radial Engineering Ltd. ProDI
™
User Guide
5
ProD2
ProDI and ProD2 Specifi cations
Frequency response: 20Hz to 20kHz +/- 2.5dB
Total harmonic distortion: 0.01 % from 20Hz to 20kHz
Input impedance: 140K ohms (with 1kHz input)
Balanced outputs: 150 ohms, -60dB mic level, pin-2 hot
PAD: -15dB
ProDI
BLOCK DIAGRAM AND SPECIFICATIONS
