45
REAR–FACING
INSTALL USING:
DO NOT install by this method for a child weighing
more than 35 lb (15.8 kg). Reinstall with vehicle
seat belt for a child weighing between 35–50 lb
(15.8–22.7 kg).
1. Install detachable rear-facing base (see pg 43).
2. Remove LATCH/UAS strap
from storage location on
back of seat. Use LATCH/UAS
red release tabs on LATCH/
UAS connectors and pull
up to remove.
LATCH/UAS
5–35 lb (2.3–15.8 kg)
2
