diono.com
73
3. Slide the new harness straps
through the buckle tongues
in the center buckle, re-attach
the chest clip and reinstall the
harness pads. Making sure the
harness straps are oriented
correctly and not twisted.
4. Re-secure the harness straps
to the metal plate. Make sure
to secure the left strap onto the
metal hook rst then secure
the second strap onto the
metal hook.
5. Tighten the harness (see pg 38).
HARNESS STRAP REPLACEMENT
2 nd
1st
3
4
