THE SAFE START MENU FLOW CHART
14
MULTI-CHEMISTRY AC/DC PEAK DETECTION BALANCE CHARGER
SELECT FUNCTION
LIFE CHARGE
SELECT FUNCTION
LIIO CHARGE
SELECT FUNCTION
LIPO CHARGE
SELECT FUNCTION
NIMH/CD CHARGE
SELECT FUNCTION
TOOLS
SELECT FUNCTION
OPTIONS
LIFE CAPACITY
6000MAH
LIIO CAPACITY
6000MAH
LIPO CAPACITY
6000MAH
NIXX CHARGE RATE
6.0A
TOOLS
BALANCE METER
TOOLS
VOLT METER
OPTIONS
LIPO STORAGE
OPTIONS
LIXX CHG MODE
OPTIONS
NIMH/CD CHG MODE
OPTIONS
DEFAULT VALUES
OPTIONS
AUDIO TONES
V:00.00 C1:0.00V
C2:0.00 C3:0.00V
INPUT: 00.000V
OUTPUT: 00.000V
LIPO CAPACITY
6000MAH
LIPXX CHG MODE
CAPACITY
NIXX CHG MODE
CURRENT
NIXX D-PEAK
8MV
AUDIO TONES
ON
AUDIO TONES
OFF
CHECKING BATT
FOR LIFE CHARGE
CHECKING BATT
FOR LIIO CHARGE
CHECKING BATT
FOR LIPO CHARGE
CHECKING BATT
FOR NIXX CHARGE
CONFIRM (6.0A)
LIFE CHARGE
3
CONFIRM (6.0A)
LIIO CHARGE
3
CONFIRM (6.0A)
LIPO CHARGE
3
CONFIRM (6.0A)
NIXX CHARGE
3
CONFIRM (6.0A)
LIPO STORAGE
3
1
2
