15
SPECIFICATIONS
PROBE
Input Current Range .................................................... 1–300 A
Output ............... 0.5 mA per amp of input current (1 mA = 2 A)
Accuracy ................................
±
0.6 A at 50 Hz/60 Hz for 1–2 A
±
(4% + 1 A) at 50 Hz/60 Hz for 2–300 A
Working Voltage ..................................... 500 V RMS maximum
Division Ratio .............................................................. 2000:1.0
Duty Cycle .............................. 30 seconds use/15 minutes rest
(Measurement Current More Than 200 A)
Shunt (Load) Resistance .................................. Less than 12
Ω
at current meter input
Jaw Opening ..................................................... 1 Inch (25 mm)
Test Lead Length ................................... 39.37 Inches (100 cm)
Operating Temperature ..................... 32 to 109.4
°
F (0 to 43
°
C)
Storage Temperature ....................... –4 to 140
°
F (–20 to 60
°
C)
Dimensions (HWD) ........................... 8
13
/16
×
3
3
/8
×
1
3
/
16
Inches
(224
×
86
×
30
mm)
Weight ............................................................ 10.4 oz (294.1 g)
AC CURRENT ADAPTER
Input Current Range ......................................... 10 A maximum
Working Voltage .......................................................... 120 VAC
Specifications are typical; individual units might vary. Specifica-
tions are subject to change and improvement without notice.
22-601.fm Page 15 Monday, August 2, 1999 3:48 PM
