7
Note:
Experiment with the receiver’s volume setting and
the settings of other components in your audio system to
obtain the best results.
Using the Standby Setting
The microphone’s
STBY
setting lets you turn off the
microphone without turning off the microphone’s
transmitter.
If you move the switch from
ON
or
STBY
to
OFF
while your
amplifier is on, there is a loud pop. There is no pop when
you move the switch from
STBY
to
ON
, or from
ON
to
STBY
.
To conserve battery power, be sure to set the switch to
OFF
when you finish using the microphone.
SPECIFICATIONS
S
ensitivity ......................................................100 dB SPL @ ± 7 kHz FM
Frequency Response.................................................... 100 – 10,000 Hz
RF Output Power ............................................................... 50 mW (Max)
Current Consumption....................................................30 mA (Average)
Battery Life (Alkaline) ..................................................8 Hours (Average)
Dimensions (Diameter
×
Length) ...............................2
3
/
8
×
9
11
/
16
Inches
(61
×
246 mm)
Operating Frequencies
Channel........................................................................Frequency (MHz)
A..................................................................................................169.445
B..................................................................................................169.505
C..................................................................................................170.245
D..................................................................................................170.305
