5
Installing the Battery
Peak Level Indication
— shows you
when the meter registers the maximum
level measurement on the bargraph.
Reset Button
— lets you clear the current
measurements from the meter’s memory
and begin a new measurement.
9-Volt Battery Operation
— lets you
power the meter with a 9-volt battery.
Phono Output Jack
— lets you connect
the meter to your stereo system or test
equipment.
Low-Battery Indicator
— shows you
when the battery needs to be replaced.
ˆ
Installing the
Battery
The meter requires one 9-volt battery for
operation. For the best operation and
longest life, we recommend RadioShack
alkaline batteries. Follow these steps to
install the battery.
