Radio Shack Digital Recorder User Manual

33
CD-ROM in the CD-ROM
drive.
2. Double-click the
CD-ROM
icon in the Explorer
window, then double-click
the
Setup
icon.
3. Install RadioShack PVR
Manager by following the
on-screen instructions.
4. After setup is complete,
click
OK
on the screen and
remove the CD-ROM from
the CD-ROM drive.
7PKPUVCNNKPI"284"
/CPCIGT
1. Click
Start/Settings/Control
Panel
, and double click
Add/Remove Programs.
2. Follow the on-screen
instructions to uninstall the
PVR Manager.

Radio Shack Digital Recorder Specifications

General

memory size	8 MB
recording time (SP)	133 minutes
recording time (MP)	177 minutes
recording time (LP)	290 minutes
recording system	Built-In Flash Memory
power supply	DC 3V, two AAA alkaline batteries
battery life in recording mode	About 16 hours
battery life in earphone play	About 16 hours
battery life in speaker play	About 10 hours
maximum number of recording messages	495 Messages
files x messages	5 Files × 99 Messages
maximum output power	60 mW, at 8 ohm, 10% THD
frequency bandwidth	500 Hz to 3000 Hz
input	Plug-in microphone (mini plug, mono)
output	Earphone (mini plug, mono) impedance is 32 ohm
speaker	Built-in 20 mm diameter
microphone	Built-in omni-directional elect condenser microphone (mono)
operating temperature	0°C to 40°C
accessory	Wrist Strap

Weight and Dimensions

dimensions	4.1 × 1 × 0.7 inches, 104 × 26 × 18 mm
weight (without batteries)	Approx. 34 g
