Radio Shack Invisible Beam Entry Alert - User Manual

20 pages

To Next Page

To Next Page

Loading...

Owner’s Manual

Please read before using this equipment.

Invisible Beam Entry Alert

Questions and Answers:

J
Joel ColemanJul 30, 2025
Why does my Radio Shack Invisible Beam Entry Alert Security System give false alarms when the infrared beam isn't broken?
- S
  Sarah WhiteJul 30, 2025
  Your Radio Shack Security System might be giving false alarms because the sensor is set out of range, causing it to operate erratically. To resolve this, position the alert and the reflector within 3 to 50 feet of each other. Also, adjust the sensitivity until the false alarms stop. Additionally, readjust and/or reposition the alert and/or reflector. Clean the lenses using a non-abrasive lens cleaning solution and a lint-free cloth.
S
Sally HunterAug 14, 2025
What to do if the external siren on my Radio Shack Invisible Beam Entry Alert Security System doesn't work?
- C
  Cheryl MillerAug 14, 2025
  If the external siren (or another connected device) of your Radio Shack Security System does not operate, the in-line fuse may be blown. Replace the fuse with one of the same size and type.

Radio Shack Invisible Beam Entry Alert Specifications

Operating Environment

approximate effective distance	2.7 to 50 feet
beam light source	Infrared LED
receiver	Infrared-Sensitive Photo-Transistor

Power

power source	120 VAC, 15W, 60 Hz
power adapter	12 VAC, 830 mA
ac input terminals	12 VAC

Dimensions

dimension	3[13]/16 × 2[15]/16× 2[9]/16 inches
dimension in millimeters	97.6 × 75.2 × 65.3 mm

Summary

Features

General Information

Installation

Choosing a Location

Describes optimal placement for the alert and reflector.

Connecting AC Power

Instructions for powering the alert using the AC adapter.

Mounting the Alert

Steps for securing the main alert unit to a wall or desk.

Mounting the Reflector

Instructions for attaching the reflector unit securely.

Aligning the Beam

Guidance on correctly positioning the beam between units.

Adjusting Sensitivity

How to fine-tune the detection sensitivity.

Connecting Optional Components and External Siren

Overview and steps for connecting external sirens or other devices.

Connecting Another External Device

Instructions for connecting other devices like phone dialers.

Backup Power and Wire Routing

Connect backup DC power and manage wiring for installation.

Operation

Using the Alert

How to activate and use the alert in different modes.

Testing the Backup DC Source

Procedure for verifying the backup power function.

Power Failure Alarm

Explanation of the alarm triggered by power loss.

Troubleshooting

Care

Replacing the Fuse

Steps to replace the internal fuse.

Lightning Protection

Advice on protecting the unit from lightning surges.

Specifications
