9
Installation
Or, follow these steps to mount the alert on a desk.
1. Place the alert on a desk and use it as a
template to mark the position of the two
screw holes on the desk.
2. Drill two
3
/
32
-inch holes in the marked
positions.
3. Thread the two supplied wood screws
through the holes on the alert and into the mounting sur-
face, then tighten the screws.
4. Plug the adapter into a standard AC outlet.
MOUNTING THE REFLECTOR
Use the supplied mounting bracket, screws and adhesive strips
to mount the reflector vertically or horizontally.
1. Using one half of the bracket as a template, mark the posi-
tion of the two screw holes.
2. Drill two
3
/
32
-inch holes in the
marked positions.
3. Thread one of the supplied wood
screws through each of the two
screw holes in the bracket and into
the mounting surface, then tighten
the screws.
