27
SPECIFICATIONS
Receiver
Frequency Coverage ... 26.965
–
27.405 MHz
Sensitivity (Max.) ..... 0.5
µ
V at 10 dB (S+N)/N
Adjacent Channel Rejection ................. 45 dB
Squelch ............Adjustable from 1
µ
V to 1 mV
Audio Output (10% THD) ................. 400 mW
Current Drain ............................... 85
–
450 mA
Transmitter
Frequency Coverage ... 26.965
–
27.405 MHz
Power Input (at 12V DC):
High ................................................. 5 W
Low .................................................. 2 W
Power Output:
High .............................................. 2.5 W
Low .................................................. 1 W
Spurious Emission ................ –67 dB or better
Type of Modulation ..................................... A3
Frequency Tolerance .......................... 0.002%
Antenna Impedance ................................ 50
Ω
Antenna Length ..................................... 10 In.
(25.4 cm)
Current Drain:
High ........................................... 650 mA
Low ............................................. 450 mA
Dimensions (HWD) ............ 7
1
/
2
×
2
3
/
4
×
2
1
/
8
In.
(190
×
70
×
54 mm)
Weight ................................................ 11.8 oz
(334 g)
Specifications are typical; individual units
might vary. Specifications are subject to
change and improvement without notice.
21-1650.fm Page 27 Thursday, August 5, 1999 11:43 AM
