RadioMaster TX16S MKII

Specifications
Size: 286.9*128.9*183.8mm
Weight: 750g (without battery)
Transmission frequency: 2.400GHz-2.480GHz
Transmitter module: 4-in-1 multi-protocol internal module -OR- ExpressLRS internal module
Transmitting power: Internal 4-in-1 multi-protocol module : Max 100mw (protocol dependent)
Internal ELRS : Max 250mw (transmitting power is adjustable)
Working current: 400mA
Working voltage: 6.6-8.4vDC
Remote control distance:> 2km @ 22dbm
Radio firmware: EdgeTX (Supports OpenTX also)
Channels: Up to 16 channels (depending on the receiver)
Display: 4.3-inch TFT full-color touch display with a resolution of 480 * 272
Gimbal: V4.0 Hall sensor with Aluminum facia -OR- AG01 CNC Hall sensor
Module Bay: JR compatible module bay
Upgrade method: Supports USB-C online / SD card offline upgrade
4
Approved for use
EU Simple Declaration of Conformity
Manufacturer by
Do not use 2s 6.6v LiFE battery pack, 18650 lithium-ion cells with a nominal voltage of 3.6v or LiFEP04
18650 Round cells. Using the built in USB charger with incorrect battery types and voltage may cause
damage to the remote control or fire.
Check the health and condition of the batteries regularly. Do not use damaged cells. Never charge your
device unattended. Always charge in a safe area away from flammable materials. If the remote control
gets wet or damaged in any way, do not charge it.
RadioMaster is not responsible for any adverse consequences caused by using or misusing this device.
RadioMaster declares the radio equipment TX16s is in compliance with EU directives Directive
2014/53/EU. Full text of the declaration of conformity is available at the following website www.radio-
masterrc.com
ShenZhen RadioMaster Co., Ltd
4F Yang Tian Building, Area 72 Xing Dong community, Xin An Street, Bao An district,
Shen Zhen city, Guangdong Province, China
2 x 3.7v Li-ION 18650 cells (7.4v using supplied tray)
2 x 3.7v Li-ION 21700 cells (Assembled as 7.4v 2s Battery pack)
2 x 3.7v Lithium-polymere cells (Assembled as 7.4v 2s Battery pack)
DO NOT use
3.6v Li-ION cells
2S 6.6v LiFE Battery packs
LiFEP04 cells
FCC ID: 2AV3G-TX16S
FCC Information
CAUTION:
This equipment has been tested and found to comply with the limits for Part 15 of the FCC
rules. This device complies with part 15 of the FCC rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation. Full
text of the declaration of conformity is available at the following website www.radiomasterrc.com
Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment. This product contains a radio transmitter with
wireless technology which has been tested and found to be compliant with the applicable
regulations governing a radio transmitter in the 2.400GHz to 2.4835GHz frequency range.
