RADLEY WS5T - Page 16

15
5-Tn Ecrc Lg Slte - Onr's Mna
45 Steel Ball 1
46 Pressure Limited 1
Valve Spring
47 Adjusting Screw 1
M8x8
48 Log Pusher 1
Connection
Weldment
49 Lower Plastic Insert 1
50 Upper Plastic Insert 1
51 Log Pusher 1
52 Nut, M10 4
53 Flat Washer, M10 5
54 Screw M10x25 4
55 Wheel Cover 2
56 R－ Clip 2
57 Wheel 2
58 Washer, M6 2
59 Wheel Bracket 1
60 Bolt M8x55 6
61 Lock Washer, M8 9
62 Spring Washer, M8 9
63 Gear Pump Cover 1
64 O-Ring 10.6x2.65 2
65 Gear Housing Plate 1
66 Circlip 10 2
67 Gear Shaft 1
68 Steel Ball 2.5 1
69 Gear 2
70 Pin 2.5x4 1
71 Flat Washer, M5 6
72 Bolt M5x185 3
73 Motor Cover 1
74 Seal FB11x26x7 1
75 Nut, M8 1
76 Screw M8x35 1
77 Motor 1
78 Fan 1
79 Block Tum 17 1
80 Fan Shroud 1
81 Lock Washer, M5 3
82 Flat Washer, M5 3
83 Screw M5x10 3
84 Front Support Leg 1
85 Nut, M8 5
86 Bolt M8x12 5
87 Plug 1
88 Cover for Switch 1
90 Strain Relief 1
91 Screw, ST4x10 6
92 Switch Box Cover 1
93 Airproof Underlay 1
94 Switch 1
95 Connection Terminal 1
96 Capacitor 1
97 Switch Box 1
98 Waterproof Underlay 1
99 Motor Support 1
Right Shoe
100 Motor Support 1
Left Shoe
101 Pin 8x24 2
102 O-Ring, 26 2x1.8 2
103 Sliding Sleeve 2
104 Bolt M8x30 3
No. Description Qty. No. Description Qty.
