PARTS LIST
WARNING: When servicing, use only original equipment replacement parts.
The use of any other parts may create a safety hazard or cause damage to the
log splitter.
Any attempt to repair or replace electrical parts on this log splitter may create a
safety hazard unless repairs are performed by a qualified technician.
Customer Service / Tech Support 1-866-206-0888.
1 Lever Mount Nut 1
2 Nut Cap, M10 3
3 Lever 1
4 Lever Knob 1
5 Guard Plate 1
6 Nut 2
7 Copper Gasket 10 4
8 Safety Valve 1
Screw M8
9 O-Ring 5.5x2 1
10 Snap Washer 6 1
11 Valve Retract Spring 1
12 O-Ring 6x1.5 1
13 Valve Core Rod 1
14 Sliding Pressure 1
Sensor Sleeve
42 Valve Sleeve 1
15 Sliding Pressure 1
Sensor Sleeve Spring
16 Aluminum Cover 1
( Rear )
17 O-Ring 55X3.1 1
18 Piston 1
19 Piston Ring 55 1
20 O-Ring 32X3.5 1
21 Spring 1
22 Stud 4
23 Hydraulic Cylinder 1
24 Aluminum Cover 1
( Front)
25 Piston Rod Seal 30 1
26 O-Ring 7x1.9 1
27 Bleed Screw M5X12 1
28 Washer 1
Groupware 14
29 Dipstick 1
30 Piston Rod 1
31 Lift Handle 1
32 Screw M6X16 2
33 Frame Tube 1
34 Support Plate 2
35 Lock Washer 6 4
36 Screw M6x10 2
37 Nut M14 2
38 Flat Washer, M14 2
39 Nut, M14 2
40 Nut Plug 1
41 Washer 1
Groupware 16
43 O-Ring 14x1.9 5
44 Adjusting Screw 1
M5x8
No. Description Qty. No. Description Qty.
To Next Page
