OPERATION
- 12 -
After the monitor is turned on, it runs through the start up
menu. Then the message “Ready..” is displayed (see figure
below). At this point, the user has two options: (1) step
through the operation menu (see below), or (2) take a
Press the [MODE] key to cycle through the main operation
menu. The PID sensor and pump are turned off during this
operation.
Main operation menu displays include:
“Ready…”
Avg reading
Peak reading
Run time
Current battery voltage and shut down voltage
Date, time, and temperature
Log on/off?
PC comm?
Ready…
measurement (see page 16).
Gas = [reference gas] (default is isobutylene)
Cancel background?
Figure 2-3. Survey mode "Ready..."
2.4.1 Survey Mode
Mode [Survey or Hygiene]
