-7-
TRANSMITTER INSTRUCTIONS
CONTROL DIRECTIONS
SMART PHONE
INSTALLATION
Up
Up
Down
Down
Rotate
Left
Rotate
Right
Rotate
Right
Rotate
Left
Forward
Forward
Backward
Backward
Left-side
Flight
Left-side
Flight
Right-side
Flight
Right-side
Flight
1. Left Control Stick (throttle/yaw)
The left stick controls the flight altitude and left and right rotation (yaw)
2. Right Control Stick (pitch/roll)
The right stick controls the forward/backward and left/right-side flight direction
1. Open the mobile phone
bracket on the transmitter.
2. Insert the mobile phone into the bracket
on the transmitter and adjust the bracket
as necessary.
