13. TROUBLESHOOTING
When the engine will not start:
•Is there enough fuel?
•Is the fuel valve on?
•Is the engine switch ON?
•Is gasoline reaching the carburetor?
To check, loosen the drain knob with the fuel valve ON. Fuel
should ow out freely.
Retighten drain knob.
WARNING: If any fuel is spilled, make sure the area is dry before testing the spark plug or
starting the engine. Fuel vapor or spilled fuel may ignite.
(1) Fuel valve
(2) ON
(3) DRAIN KNOB
•Is there a spark at the spark plug?
•Remove the spark plug cap. Clean any dirt from around the spark plug base, then remove the spark plug.
•Install the spark plug in the plug cap.
•Turn the engine switch on.
•Grounding the side electrode to any engine ground, pull the recoil starter to see if sparks jump
across the gap.
•If there is not spark ,replace the plug.
If OK, try to start the engine according to the instructions.
•If the engine still does not start, take the tiller to an authorized dealer.
RO
Instructiuni de folosire
Date tehnice
parametru unitate Value
Model - RD-T08
Engine
capacitatea cilindrică cm
3
208
putere kW / HP 5.2 / 7.0
cuplul maxim Nm / rpm 12/2500
sistem de aprindere - ignition coil
sistemul de pornire - Hand starter
Capacitatea rezervorului de combustibil L 3.6
Consum de combustibil g/kw*h ≤395
Capacitate rezervor ulei L 0.600
nivelul de zgomot dB 86
mișcare - belt
Lățimea arat mm 500-1000
adâncime Tilling mm 150-300
Cutie de viteze - 2-front, 1-rear gears
tipul de ulei - SAE30-5W30/10W40
ulei cutie de viteze - transmition oil
greutate kg 75
cilindru singură, 4 timpi, racit cu aer
