Attention: Important Operational Information. Please Read Before Installation.
•
The loudspeaker may be operated only with the system-synchronized crossover and under
observance of the specified rated output power.
•
Interchanging the woofer and tweeter connections will lead to immediate destruction of the tweeter.
•
Beginning operation without the crossover, for example with an active crossover or non-system
crossover, will result in damage to the loudspeaker.
•
The tweeter is not intended for active operation without passive crossover. Disregarding this will
thermically damage the tweeter by feeding it at too-high power levels.
•
When connecting the loudspeaker, crossover, and amplifier it is absolutely necessary to employ the
same polarity. Interchanging the polarity produces an unnatural sound lacking bass reproduction.
•
The component systems are acoustically synchronized as one unit. Supplementation through an
auxiliary loudspeaker or tradeout with a larger woofer is not possible as this would change the overall
frequency response or impedance of the system. An overload of the crossover or a single
loudspeaker would then be unavoidable.
•
The opening of the crossover for the purpose of altering the parts or function, for example bi-amping,
is considered foreign interference and grounds for termination of the warranty
•
For the purpose of technical safety, the loudspeaker should only be attached with the included self-
tapping screws. We accept no liability for use of alternative methods of attachment.
Contents and Detail of Parts
EL-C5.2 / EL-C6.2
Fastening for Woofer:
2 (4) pieces woofer 130 / 165 mm ∅ B
8 (16) pieces self-tapping screw 3,9 x 32 DIN 7981 black G
8 (16) pieces washer M4 DIN black H
8 (16) pieces self-tapping nut 3,9 DIN galvanized I
Fastening for Tweeter:
2 pieces EL-T19 Silk (cable connection) J
2 pieces fastening ring M
2 pieces tweeter stand ring O
2 pieces intermediate ring
2 pieces flush mount cup U
2 pieces angle mount cup S
2 pieces Dashboard bracket
Fastening for Crossover:
2 pieces cable crossover W
Miscellaneous:
1 piece installation manual
