TOOLS REQUIRED FOR ASSEMBLY
Tape Measure
Carpenters Level
Carpenters Square
Rubber Mallet
Claw Hammer
Wood Clamp
Standard or Cordless Drill
with #2 & #3 Phillips Bits
Electric Impact Gun or 1/4"
and 3/8" Ratchet
1/8" Drill Bit
1/4" Drill Bit
Torque Wrench
Crescent Wrench
7/16" Deep Well Socket
1/2" Deep Well Socket
9/16" Deep Well Socket
9/16" Box Wrench
8' Step Ladder
Safety Glasses
Adult Helper
*DENOTES HARDWARE BAG
**DENOTES QUANTITY NEEDED OUT OF HARDWARE BAG
NOTE: EXTRA HARDWARE IS INCLUDED IN THE BAGS.
NOT ALL HARDWARE WILL BE USED TO COMPLETE THE INSTALLATION.
EXAMPLE:
5-46-0506* @ 2**
Funhouse Hardware List
F/N#
DESCRIPTION
DIMENSION
BAG/QTY
H1
Flat Washer
1/4"
5-46-0506 @2, 5-46-0514 @80
H3
Flat Washer
3/8"
5-46-0410 @4, 5-46-0506 @23, 5-46-0514 @6
H4
Flat Washer
1/2"
5-46-0506 @4, 5-46-0514 @2
H7
SAE Washer
1/4"
5-46-0514 @28
H11
Lock Washer
3/8"
5-46-0410 @4, 5-46-0506 @20, 5-46-0514 @10
H17
Standard Nut
3/8"
5-46-0506 @5, 5-46-0514 @2
H24
Nylock Nut
3/8"
5-46-0410 @4, 5-46-0506 @8
H28
Acorn Nut
3/8"
5-46-0410 @4, 5-46-0506 @13, 5-46-0514 @2
H30
Round Pallet Nut
3/8"
5-46-0506 @6, 5-46-0514 @4
H32
4 Prong T-Nut
1/4"
5-46-0514 @32
H34
4 Prong T-Nut
3/8"
5-46-0514 @4
H50
Carriage Bolt
3/8" x 3 1/2"
5-46-0506 @2
H56
Carriage Bolt
3/8" x 6 1/2"
5-46-0506 @1, 5-46-0514 @2
H60
Carriage Bolt
3/8" x 8 1/2"
5-46-0506 @1
H93
Lag Bolt
1/4" x 2"
5-46-0514 @6
H108
Lag Bolt
5/16" x 3"
5-46-0506 @2, 5-46-0514 @80
H116
Lag Bolt
3/8" x 3 1/2"
5-46-0506 @2
H124
Hex Bolt
3/8" x 1 1/2"
5-46-0514 @4
H126
Hex Bolt
3/8" x 2"
5-46-0506 @2
H129
Hex Bolt
3/8" x 3 1/2"
5-46-0506 @3
H131
Hex Bolt
3/8" x 4 1/2"
5-46-0514 @4
H135
Hex Bolt
3/8" x 6 1/2"
5-46-0410 @4, 5-46-0506 @8
H139
Hex Bolt
3/8" x 9"
5-46-0506 @1
H140
Hex Bolt
3/8" x 10"
5-46-0506 @1
H152
Phillips Wood Screw
#8 x 1 1/2"
5-46-0514 @279
H155
Phillips Wood Screw
#8 x 2 1/2"
5-46-0514 @62
H158
Phillips Pan Head Tap Screw
#10 x 1 1/2"
5-46-0514 @4
H163
Phillips Pan Head Tap Screw
#14 x 3/4"
5-46-0514 @6
H164
Phillips Pan Head Tap Screw
#14 x 1"
5-46-0514 @26
H170
Phillips Pan Head Machine Screw
1/4" x 1 1/4"
5-46-0514 @24
H192
Phillips Pan Head Machine Screw
1/4" x 1 1/2"
5-46-0514 @8
17
