D
15
52
N1
1. Insert Rope
(N1)
into hole in 4 Hole Facia with Rope Hole
(52)
and tie a double knot on the back
side of the board. Tie three single knots evenly spaced along the remaining Rope. Insert end of
Rope
(N1)
into hole in Rockwall Board
(15)
and tie a double knot on the back side of the Rockwall.
*NOTE: Rope must be secure at both ends and must be tight enough that it cannot be be
looped back on itself.
37
Step 19
Rockwall Rope Installation
