TOOLS REQUIRED FOR ASSEMBLY
Tape Measure
Carpenters Level
Carpenters Square
Rubber Mallet
Claw Hammer
Wood Clamp
Standard or Cordless Drill
with #2 & #3 Phillips Bits
7/16" Deep Well Socket
1/2" Deep Well Socket
9/16" Deep Well Socket
9/16" Box Wrench
8' Step Ladder
Safety Glasses
Adult Helper
Electric Impact Gun or
1/4" and 3/8" Ratchet
1/8" Drill Bit
7/16" Drill Bit
Torque Wrench
Crescent
R
Wrench
*NOTE: EXTRA HARDWARE IS INCLUDED IN THE BAGS.
NOT ALL HARDWARE WILL BE USED TO COMPLETE THE INSTALLATION.
Super Funhouse Hardware List
F/N#
DESCRIPTION
DIMENSION
QTY
FOUND IN
H1
Flat Washer
1/4"
112
5-46-0781
H3
Flat Washer
3/8"
6
5-46-0781
H4
Flat Washer
1/2"
2
5-46-0781
H7
SAE Washer
1/4"
42
5-46-0781
H9
Lock Washer
1/4"
4
5-46-0781
H11
Lock Washer
3/8"
6
5-46-0781
H17
Standard Nut
3/8"
2
5-46-0781
H28
Acorn Nut
3/8"
2
5-46-0781
H32
4 Prong T-Nut
1/4"
24
5-46-0781
H34
4 Prong T-Nut
3/8"
4
5-46-0781
H55
Carriage Bolt
3/8" x 6"
4
5-46-0781
H63
Carriage Bolt
3/8" x 11"
1
5-46-0781
H93
Lag Bolt
1/4" x 2"
6
5-46-0781
H104
Lag Bolt
5/16" x 2"
12
5-46-0781
H108
Lag Bolt
5/16" x 3"
100
5-46-0781
H129
Hex Bolt
3/8" x 3 1/2"
4
5-46-0781
H176
Phillips Wood Screw
#8 x 1"
8
5-46-0781
H194
Phillips Wood Screw
#8 x 1 1/4"
176
5-46-0781
H152
Phillips Wood Screw
#8 x 1 1/2"
174
5-46-0781
H155
Phillips Wood Screw
#8 x 2 1/2"
12
5-46-0781
H157
Phillips Pan Head Tap Screw
#10 x 1"
8
5-46-0781
H163
Phillips Pan Head Tap Screw
#14 x 3/4"
2
5-46-0781
H164
Phillips Pan Head Tap Screw
#14 x 1"
10
5-46-0781
H166
Phillips Pan Head Tap Screw
#14 x 1 1/2"
4
5-46-0781
H203
Phillips Pan Head Machine Screw
1/4" x 3/4"
4
5-46-0781
H170
Phillips Pan Head Machine Screw
1/4" x 1 1/4"
18
5-46-0781
H192
Phillips Pan Head Machine Screw
1/4" x 1 1/2"
2
5-46-0781
10
