www.raisecom.com User Manual
2
interface (SC-PC), single-strand, two-wavelength, Tx wavelength
1310nm, transmission distance 10~50km
RC832-30-SS25 Modular device, 1 75Ω unbalanced E1 interface (DB-9), 1 optical
interface (SC-PC), single-strand, two-wavelength, Tx wavelength
1550nm, transmission distance 10~50km
RC832-30-BL-S1 Modular device, 1 120Ω balanced E1 interface (RJ-45), 1 optical
interface (DSC), dual-strand, single-mode, transmission distance
0~25km.
RC832-30-BL-S2 Modular device, 1 120Ω balanced E1 interface (RJ-45), 1 optical
interface (DSC), dual-strand, single-mode, transmission distance
10~60km.
RC832-30-BL-S3 Modular device, 1 120Ω balanced E1 interface (RJ-45), 1 optical
interface (DSC), dual-strand, single-mode, transmission distance
15~120km.
RC832-30-BL-SS13 Modular device, 1 120Ω balanced E1 interface (RJ-45), 1 optical
interface (SC-PC), single-strand, two-wavelength, Tx wavelength
1310nm, transmission distance 0~25km
RC832-30-BL-SS15 Modular device, 1 120Ω balanced E1 interface (RJ-45), 1 optical
interface (SC-PC), single-strand, two-wavelength, Tx wavelength
1550nm, transmission distance 0~25km
RC832-30-BL-SS23 Modular device, 1 120Ω balanced E1 interface (RJ-45), 1 optical
interface (SC-PC), single-strand, two-wavelength, Tx wavelength
1310nm, transmission distance 10~50km
RC832-30-BL-SS25 Modular device, 1 120Ω balanced E1 interface (RJ-45), 1 optical
interface (SC-PC), single-strand, two-wavelength, Tx wavelength
1550nm, transmission distance 10~50km
LNote: Among RC83X series devices with optical transceivers for dual-strand fiber, the devices with same
optical transceivers can inter-connect with each other. For example, RC832-30-BL-S1 can be inter-connected
with RC831-30-FV35-S1, RC832-30 -S1 and other RC83X series devices with S1 optical transceivers.
Among RC832 series devices adopting optical transceivers for single-strand fiber, device with SS13 can
communicate with device with SS15, while device with SS23 can communicate with device with SS25. For
example, RC832-30-BL-SS13 can be inter-connected with RC832-30-BL-SS15, RC831-30-FV35-SS15 and
other RC83X series devices with SS15 optical transceivers.
