Chapter 1 Product Overview
1.1 Overview
RC832-30(-BL) is a modular PDH multiplexer of a fiber optic transmission device applicable to
point-to-point network or network with small or medium capacity, like wireless communication base
station, private networks, switch network and etc. RC832-30(-BL) series PDH multiplexer realizes
the transmission of 1 line of E1 service. It operates in chassis developed by Raisecom and is
generally applied to central site networking. The device is SNMP manageable.
1.2 Function features
¾ Single E1 transmission capability
¾ Remote device power-off detection and alarm notification
¾ In support of ALS function
¾ Local and remote E1 loopback testing function makes fault removal easier
¾ Local and remote SNMP manageable.
Remote stand-alone devices are under management.
¾ Adopt grand-scale ASIC chip
Low power consumption
4-layer circuit board design guarantees high reliability.
1.3 Ordering information
Device Description
RC832-30-S1 Modular device, 1 75Ω unbalanced E1 interface (DB-9), 1 optical
interface (DSC), dual-strand, single-mode, transmission distance
0~25km.
RC832-30-S2 Modular device, 1 75Ω unbalanced E1 interface (DB-9), 1 optical
interface (DSC), dual-strand, single-mode, transmission distance
10~60km.
RC832-30-S3 Modular device, 1 75Ω unbalanced E1 interface (DB-9), 1 optical
interface (DSC), dual-strand, single-mode, transmission distance
15~120km.
RC832-30-SS13 Modular device, 1 75Ω unbalanced E1 interface (DB-9), 1 optical
interface (SC-PC), single-strand, two-wavelength, Tx wavelength
1310nm, transmission distance 0~25km
RC832-30-SS15 Modular device, 1 75Ω unbalanced E1 interface (DB-9), 1 optical
interface (SC-PC), single-strand, two-wavelength, Tx wavelength
1550nm, transmission distance 0~25km
RC832-30-SS23 Modular device, 1 75Ω unbalanced E1 interface (DB-9), 1 optical
