Raisecom RC832-30 User Manual

www.raisecom.com User Manual
9
DIP switch SW2
The DIP switch SW2 identifies the optical transceiver type adopted by the device. The settings of
SW2 are completed by the manufacturer. Please keep the factory settings of SW2. They are not
allowed to be changed.
SW2-1 SW2-2 SW2-3 SW2-4 Optical transceiver Type
ON ON ON ON M (1310 Tx&Rx)
ON ON ON OFF S1 (1310 Tx&Rx)
ON ON OFF ON S2 (1310 Tx&Rx)
ON ON OFF OFF S3 (1550 Tx&Rx)
ON OFF ON ON SS13 (1310 Tx, 1550 Rx)
ON OFF ON OFF SS15 (1550 Tx, 1310 Rx)
ON OFF OFF ON SS23 (1310 Tx, 1550 Rx)
ON OFF OFF OFF SS25 (1550 Tx, 1310 Rx)
4.1.3 Default Settings
The default settings of all bits of SW1 are OFF.
