Raisecom RC832-30 User Manual

www.raisecom.com User Manual
6
E1 unbalanced interface
1 pair of BNC connectors provides 1 line of 75Ω unbalanced E1 signal.
OUT: E1 output
IN: E1 input
RC832-30-BL
1 E1 balanced interface:
1 RJ-45 interface provides 1 line of 120Ω balanced E1 signal.
Pin 1 and 2 output; pin 4 and 5 input
Pin 3, 6, 7, 8 are unused
L
Note: Please be sure that the pin arrangement of the connector of the balanced cable is correct. Please read
the instructions for cable making with caution before making cable.

Raisecom RC832-30 Specifications

General

Brand	Raisecom
Model	RC832-30
Category	Multiplexer
Language	English
