RCMS2902-2E1GE-BL Product Description
4 DIP switch
Raisecom Technology Co., Ltd.
11
SW1
Description
ON
OFF
4
th
Switch
Automatic reorganization
of master and slave
modes at the NView
NNM system
Forcibly work in slave
mode.
Automatically
recognize the working
mode.
5
th
Switch
Configure BERT.
Enable BERT.
Disable BERT.
6
th
Switch
Configure optical
interface force 100
Mbit/s.
The device is forced
to work in 100 Mbit/s
mode.
The working mode
(1000 Mbit/s or 100
Mbit/s) of the device
is adapted
automatically based on
the optical module
7
th
Switch
Enable/Disable loopback
on all E1 tributaries.
The loopback is
performed on all E1
tributaries.
No loopback is
performed on all E1
tributaries.
8
th
Switch
Select the local/remote
E1 loopback location.
Perform E1 local
directional loopback.
Perform E1 remote
internal loopback.
You can use the 4
th
switch to configure the working mode of the RCMS2902-2E1GE-
BL. When the switch is ON, the RCMS2902-2E1GE-BL is forced to work in slave
mode. When the switch is OFF, the network management card or network
management module inserted into the chassis, such as the RC002, automatically
recognizes a working mode.
For example, if the RCMS2902-2E1GE-BL is inserted into the RC002-16 chassis at
local and is inserted at the RC001-1M single-slot chassis at remote, the RCMS2902-
2E1GE-BL at local works in master mode and the one at remote works in slave mode.
As shown in Table 4-1, you can configure E1 loopback test through the DIP switch on the
RCMS2902-2E1GE-BL.
When you configure E1 loopback test through the DIP switch, the local E1 loopback is a
bidirectional one and the remote E1 loopback is a unidirectional internal one. Figure 4-2 and
Figure 4-3 show the location and direction of the local bidirectional loopback and remote
unidirectional internal loopback.
