Figure 3: RAK4631 Connection to WisBlock Base and other WisBlock Modules
Assembling and Disassembling of WisBlock Modules
Assembling
Figure 4 shows how to mount the RAK4631 module on top of a WisBlock Base board (RAK5005-O). Follow
carefully the procedure defined in WisBlock module assembly/disassembly instructions in order to secure the
connection safely. Once attached, carefully fix the module with one or more pieces of M1.2 x 3 mm screws
depending on the module.
Figure 4: RAK4631 Mounting Sketch
Disassembling
The procedure in disassembling any type of WisBlock modules is the same.
1. First, remove the screws.
